Description
3.5" x 7.875" x 2.5" DA HYD CYL
Unused old inventory. Double acting hydraulic cylinder. Numbers on cylinder 7996HCS

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke 3.5" x 7.875"
  • Barrel Thickness 0.255"
  • Gland Retainer Snap ring
  • Pressure 2500 PSI max.
  • Rod Dia. 2.5"
  • Ports SAE 8
  • Retracted Length 13.75"
  • Gland Face to Rod Pin Center 1.5"
  • Shpg. 42 lbs.
END MOUNTINGS
  • Rod End Circular Plate w/ Four Bolt Flange
  • Flange Dimensions 5" x 0.625" x 5" flange w/ four, 0.53" holes on 3.895" centers
  • Plate Dimensions 6" dia. x 3/4" thick
  • Base End Flat
  • Dimensions 3.99" dia.
