2x5x1 DA Hydraulic Cylinder

Item Number: 9-12506

Price: $49.95
TOP
Back to top

2x5x1 DA Hydraulic Cylinder

  • 2x5x1 DA Hydraulic Cylinder
  • 2x5x1 DA Hydraulic Cylinder - Alternate 1
  • 2x5x1 DA Hydraulic Cylinder - Alternate 2

2x5x1 DA Hydraulic Cylinder

item number: 9-12506 PRICE: $49.95 Out of Stock - No Longer Available
Calculate Shipping for Item 9-12506
2x5x1 DA Hydraulic Cylinder
Item Number: 9-12506
Price: $49.95
Estimate shipping to:
Shipping Notes:
* UPS 3-Day, 2-Day, and Next Day orders entered before 1pm (CST) Mon-Fri will be shipped the same day. Orders entered Sat or Sun will be shipped the following Monday.
Description
DESCRIPTION
2" x 5" x 1" DA HYD CYL
New. Double acting hydraulic cylinder. HANNA numbers on cylinder TCA22921PP.

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke 2" x 5"
  • Barrel Thickness 0.140"
  • Gland Retainer Welded
  • Pressure 2000 PSI
  • Rod Dia. 1"
  • Extend Port SAE 6
  • Retract Port SAE 4
  • Retracted Length 10.875"
  • Gland Face to Rod Pin Center 1.75"
  • Shpg. 10 lbs.
END MOUNTINGS
  • Rod End Swivel Eye
  • Width 0.71"
  • Pin-Center-To-Swivel Eye-End 1.14"
  • Swivel Eye Width 1"
  • Pin Hole 3/4"
  • Base End Thru-Hole
  • Width 2.25"
  • Pin Center to Base End 0.75"
  • Pin Hole 3/4"
