Description
DESCRIPTION
4" x 65" 2.5" DA HYD CYL
Unused old inventory. Double acting hydraulic cylinder. Rod end is machined down to 1.371" dia. x 1.125" long. Numbers on cylinder 81953 092LT0605 100JT0011RMT.

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke 4" x 65"
  • Barrel Thickness 0.255"
  • Gland Retainer Threaded in gland
  • Pressure 3000 PSI
  • Rod Dia. 2.5"
  • Ports SAE 12
  • Retracted Length 77.25" (same as overall length)
  • Gland Face to Rod Pin Center 1.5"
  • Shpg. 222 lbs.
END MOUNTINGS
  • Rod End Centered Stud, Tapped
  • Thread size-Pitch 5/8"-11
  • Thread Depth 1.5"
  • Base End Centered Stud, Tapped
  • Thread size-Pitch 5/8"-11
  • Thread Depth 1.5"
  • Stud Dimensions 1.371" dia.  x 1.125" long
