9.9 cu in Charlynn 4000 Series Motor SAE 4B Mount

9.9 cu in CHAR-LYNN 109-1012-006 HYD MOTOR
New CHAR-LYNN 4000 series hydraulic motor. Geroler power element. Tapered roller bearings on output shaft for high axial and radial load capacity.

SPECIFICATIONS

• Disp. 9.9 cu. in. / rev.
• Motor Type Geroler
• Pressure:
    3000 PSI cont.
    4500 PSI int.
• Torque:
    4290 in-lbs. cont.
    6240  in-lbs. int.
• Speed:
    582  RPM cont.
    693 RPM int.
• Flow:
    25 GPM cont.
    30 GPM int.
• Rotation Reversible
• Mount 4 bolt SAE B
• Shaft 1-1/4-14 tooth splined x 1.5"
• Ports 3/4" Split Flange (code 61)
• Case Drain SAE 4
• Size 8.85" x 5.25" x 4.71"
• Shpg. 44 lbs.
