48 Tooth 60 Pitch QD Bushed Bore Roller Chain Sprocket 60SF48H

48 Tooth 60 Pitch QD Bushed Bore Roller Chain Sprocket 60SF48H
Brand new. Quick detachable bushed bore roller chain sprocket. One-piece forged construction, hardened teeth. Black oxide finish. QD Bushing is sold separately.

SPECIFICATIONS

• Pitch 60
• Number of Teeth 48
• Model Number 60SF48H
• Outside Diameter 11.89"
• Bushing Series Required SF
• Max. Bore 2-15?16"
• Pitch Diameter 11.467"
• Hub Type B (Hub on one side)
• Length Through Bore 1-1/4"
• Hub Diameter 4-5/8"
• Shpg. 15 lbs.



---

Compatible QD Bushings (Sold Separately)




SF Series QD Keyed Bushings
Bore	Keyway	Item Number
1"	1/4"	1-5678-SF-F
1-1/8"	1/4"	1-5678-SF-G
1-3/16"	1/4"	1-5678-SF-H
1-1/4"	1/4"	1-5678-SF-I
1-3/8"	5/16"	1-5678-SF-J
1-7/16"	3/8"	1-5678-SF-K
1-1/2"	3/8"	1-5678-SF-L
1-5/8"	3/8"	1-5678-SF-N
1-3/4"	3/8"	1-5678-SF-O
1-11/16"	3/8"	1-5678-SF-1-1116
1-7/8"	1/2"	1-5678-SF-P
1-15/16"	1/2"	1-5678-SF-Q
2"	1/2"	1-5678-SF-R
(Bushings Sold Separately)

SF Series QD Keyed Bushings
Bore	Keyway	Item Number
2-1/8"	1/2"	1-5678-SF-2-18
2-3/16"	1/2"	1-5678-SF-2-316
2-15/16"	5/8"	1-5678-SF-516
2-1/4"	1/2"	1-5678-SF-U
2-3/8"	5/8"	1-5678-SF-V
2-7/16"	5/8"	1-5678-SF-W
2-1/2"	5/8"	1-5678-SF-2-12
2-5/8"	5/8"	1-5678-SF-Y
2-11/16"	5/8"	1-5678-SF-2-1116
2-3/4"	5/8"	1-5678-SF-2-34
2-13/16"	3/4"	1-5678-SF-2-1316
2-7/8"	3/4"	1-5678-SF-2-78
2-15/16"	3/4"	1-5678-SF-2-1516
(Bushings Sold Separately)
