3/8" NPT 0-8 GPM Flow Control w/Relief Valve Dynamic DFC-R-51-3/8-N

HYDRAULIC FLOW CONTROL
Brand new, Dynamic DFC-R-51-3/8-N full-range pressure compensating variable flow control. Features a cast iron body, heat treated compensator spool and a stainless steel rotary spool. Designed so that the orifice area varies as the lever is rotated. The outlet flow is smooth and constant regardless of the pressure on the control flow or excess flow ports. An adjustable ball spring relief allows for pressure compensated flow up to the pressure setting on the relief with accuracy to 150 psi. Relief valves are preset at 2100 psi and field adjustable from 75 to 3000 psi.

SPECIFICATIONS

• Brand Dynamic
• Model DFC-R-51-3/8-N
• Pressure 3000 PSI max.
• Variable Flow 0-8 GPM
• Relief Valve Adjustable 75 to 3000 PSI, preset to 2100 PSI
• Ports 3/8" NPT
• Mount Two 17/64" holes thru body on 3.87" centers
• Size 5.78" x 4.56" x 2.87"
• Shpg 11 lbs.
