Description
FAIRFIELD MFG. TORQUE HUB
New, Fairfield Mfg. W3B110354 wheel drive torque hub. Hydraulic motor not included. Sold with motor shaft coupler. Ideal for propelling off-highway equipment, to power winches and marine applications.

SPECIFICATIONS
  • Brand Fairfield Mfg.
  • Model Number 7970000994
  • Part Number W3B110354
  • Series 3
  • Reduction Ratio 53.58:1
  • Torque
       37500 in-lbs. Continuous
       75000 in-lbs. Intermittent
       100000 in-lbs. Peak
  • Input Speed 3000 RPM max.
  • Output Speed 56 RPM max.
  • Radial Load 14000 lbs. max.
  • Motor Mount Two Bolt SAE B, Two 1/2"-13 tapped holes on 5.75" B.C. w/ 4" pilot
  • Motor Mount Input Shaft 13T spline
  • Spindle Mount Dia. 9.5"
  • Spindle Pilot Dia. 8"
  • Spindle Mount Bolt Circle Eight 0.66" dia. holes on 9.5" B.C.
  • Output Hub Dia. 15.43"
  • Wheel Pilot Dia. 11"
  • Wheel Hub Bolt Circle 13.1875" B.C.
  • Wheel Studs Ten, 3/4"-16 TPI x 1.57" studs
  • Overall Length 12.2"
  • Shpg 248 lbs.
