1.625x13x1 Double Acting Hydraulic Cylinder

Item Number: 9-13500

Price: $79.95
TOP
Back to top

1.625x13x1 Double Acting Hydraulic Cylinder

  • 1.625x13x1 Double Acting Hydraulic Cylinder
  • 1.625x13x1 Double Acting Hydraulic Cylinder - Alternate 1
  • 1.625x13x1 Double Acting Hydraulic Cylinder - Alternate 2

1.625x13x1 Double Acting Hydraulic Cylinder

item number: 9-13500 PRICE: $79.95 Out of Stock - No Longer Available
Calculate Shipping for Item 9-13500
1.625x13x1 Double Acting Hydraulic Cylinder
Item Number: 9-13500
Price: $79.95
Estimate shipping to:
Shipping Notes:
* UPS 3-Day, 2-Day, and Next Day orders entered before 1pm (CST) Mon-Fri will be shipped the same day. Orders entered Sat or Sun will be shipped the following Monday.
Description
DESCRIPTION
1.625" x 13" x 1" HYDRAULIC CYLINDER
Unused old inventory. Welded, double acting hydraulic cylinder.

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke 1.625" x 13"
  • Gland Retainer Externally threaded
  • Pressure 2500 PSI max.
  • Rod Dia. 1"
  • Ports 1/4 NPT
  • Retracted Length 18.75"
  • Gland Face to Rod Pin Center 1.5"
  • Shpg. 13 lbs.
END MOUNTINGS
  • Rod End Thru-Hole
  • Width 1"
  • Pin Center to Base End 0.6265"
  • Pin Hole 0.625"
  • Base End Tang
  • Width 0.983"
  • Pin-Center-To-Tang-End 0.673"
  • Pin Hole 0.75"
