12 Volt DC Clutch with 5.5" dia. 8-Groove Serpentine Pulley Ogura MA-N05

12 VOLT DC SERPENTINE BELT CLUTCH
Brand new, Ogura MA-N05 12 volt DC, 8 groove serpentine pulley, clutch. Primarily designed as air conditioning compressor clutches, but can also be used as clutches for hydraulic pumps, high pressure piston pumps, vacuum pumps and centrifugal pumps. Hydraulic clutch pump applications include tow trucks, marine winch drives and boom trucks in the utilities industry. Mounting hardware included.

SPECIFICATIONS

• Brand Ogura
• Model MA-N05
• Part Number 515376
• Voltage 12 Volt DC
• Pulley 5.5" dia. 8 Groove Serpentine
• Torque 90 ft lbs.
• Wattage 47 Watts
• Max. RPM 3600
• Rotation CW
• Mount Four 0.252" dia. holes on 3.396" x 4.562" centers
• Bore 0.841" tapered with 5/8"-11 TPI threads and 0.16" x 0.11" keyway
• Size 5.475" dia. x 2.323"
• Shpg 10 lbs.
