1 HP 6 GPM 230 Volt AC Submersible Well Pump R30610A-01

4" SUBMERSIBLE DEEP WELL PUMP
New, WATER ACE model R30610A-01 4" diameter, three wire, submersible deep well pump. Stainless steel housing. Water cooled motor. Number of wires does not include the ground wire.

SPECIFICATIONS

Voltage 230 VAC Amperage 8.2 Amps Power 1 Hp Phase 1 Duty Cont. Number of Wires Three

Nominal Flow 6 GPM Discharge port 1-1/4" NPT Speed 3450 RPM Size 4" diam. X 33" Shpg. 36 lbs.

Flow Rate (GPM) vs. Well Depth ft.
Well Depth		125''	150''	175''	200''	250''	300''	350''	400''	450''	500''
Flow		8 GPM	7.8 GPM	7.6 GPM	7.4 GPM	6.8 GPM	6.3 GPM	5.7 GPM	4.9 GPM	3.9 GPM	2.5 GPM
